Heavy Planer Milling Grinding Machine

Heavy Planer Milling Grinding Machine
Heavy Planer Milling Grinding Machine
Product Code : BXM20
Brand Name : Zl
Product Description

We are the renowned manufacturer, exporter and supplier of Heavy Planer Milling-Grinding Machine. Widely used for various industrial applications, this machine is provided to our customers in various technical applications. In order to make this machine first choice in the market, we use premium quality materials and cutting edge technology. Before dispatching, this machine is fully checked under various parameters so that a faultless product is delivered to our customers end. Moreover, this Heavy Planer Milling-Grinding Machine is available with below discussed

Key Features.

BXM20 series heavy planer milling machines

BXM220A

BXM220B

BXM220C

BXM220D

BXM220E

BXM225B

BXM225C

BXM225D

BXM230B

Max.allowable dimensions of workpiece

Length mm

4000

6000

8000

10000

12000

6000

8000

10000

12000

Width mm

2000

2000

2000

2000

2000

2500

2500

2500

3000

Height mm

1500

1500

1500

1500

1500

1500

1500

1500

1500

Max.machining weight

kg

18000

22000

32000

40000

48000

28000

35000

40000

45000

Main motor power

kw

30

37

45

55

55

45

55

75

75



Table

Length mm

4000

6000

8000

10000

12000

6000

8000

10000

12000

Width mm

1600

1600

1600

1600

1600

2200

2200

2200

2600

Allowable pull of rack

100000 (N)

Speed m/min

0.08-30 Stepless

Dis.between columns

mm

2020

2020

2020

2020

2020

2520

2520

2520

3020

Feeding rate of vertical tool rest

Horizontal mm

0.2-25 Stepless

Vertical mm

0.2-25 Stepless

Feeding rate of side tool rest

mm

0.2-12 Stepless

Up/down speed of beam

mm/min

360

Max.sectional area of planing arbor

mm

60 x 60

External dimensions

Length mm

8700

12700

16700

20700

24700

12700

16700

20700

24700

Width mm

4300

4300

4300

4300

4300

4800

4800

4800

5300

Height mm

3500

3500

3500

3500

3500

4200

4200

4200

4650
