Gear Shaper Machine

Gear Shaper Machine
Gear Shaper Machine
Product Code : GS
Brand Name : ZAOZHUANG
Product Description

Gear Shaper Machine

We are ISO 9001:2008 certified firm, engaged in manufacturing, exporting and supplying a wide array of Gear Shaper Machine. This machine is manufactured under the surveillance of dexterous professionals using quality examined components at our technically sound production unit. Offered machine is extensively used in various industries for cutting teeth of internal and external gears. Furthermore, our precious clients can buy this Gear Shaper Machine from us at reasonable rates.

Gear Shaper Machine is ideal for cutting the teeth of external / internal gears. This is designed & engineered to offer great cutting capabilities. It incorporates reliable components and latest technologies, as a result the machine is perfect in terms of precision, performance and volume. We have various models available for all your gears cutting needs. Also, our Gear Shaper Machine is good in aspects of speeds, controls and safety. The machine is built with robust castings, world-class components and features. It is just perfect for the production of gears with an excellent added value.

Key Features:

  • Perfect cutting with higher speeds
  • Advanced and high-precision technologies
  • Flexibility to support any gear type
  • Automation for loading / unloading
  • Easier, user friendly operation
  • High production with economically sound

Key Points:

  • Rugged construction
  • Power efficient
  • Low maintenance
  • Easy to operate

 Specifications:

Model
BC6050/BC6065
BC6063/BC6066
BC6085
BC60100
Maximum cutting
length(mm)
500/650
630/660
850
1000
Maximum distance
From
ram bottom to
table surface(mm)
525/630
385
400
800
Maximum table
horizontal travel(mm)
370/380
630
710
400
Maximum table
vertical travel(mm)
270/315
360
360
380
Dimensions of table
top surface(L×W)(mm)
440—360/630—400
630—400/660—400
800—450
1000—500
Travel of tool
head(mm)
120
120
160
160
Number of ram

reciprocation per minute

14、20、28、
40、56、80
14、20、28ã€
40、56、80
17、24、35、
50、70、100
15、20、29、
42、58、83
Swivel of tool
head
±60°
Maximum size o
f tool shank(W—T)(mm)
20—30
20—30

30—45
Range of
table power
feed
Horizontal
(mm)
0.2~2.5
0.2~2.5
0.25~3  12steps
0.3~3  10steps
Vertical
(mm)
0.08~1.00
0.08~1.00
0.12~1.5 12steps
0.15~0.5  8steps
Table rapid feed
horizontal (mm)
0.95

1.2
3
vertical(mm)
0.38

0.58
0.5

Width of central T-slot of table(mm)

18
18
22
22
Power of motor(kw)
3
3
5.5
7.50

Overall dimensions(L—W×H)(mm)

2160—1070—1194
2382—1210—1504

2342—1225—1480
 2357—1225—1480

2950—1325—1693
3640—1575—1780
N.W/G.W(kg)
1650       2200
1750/1870 1800/1920
2940/3090
4870/5150
